6-track 32-bit float recorder with Dual A/D Converters
Clip-free recording with no need to set gain
Records up to 96kHZ sample rate
Interchangeable Mic Capsule System 3.0 with 32-bit float support
Included X/Y Mic Capsule captures up to 135 dB SPL
4 XLR/TRS combo inputs with locking connector
Color LCD Screen
Built-in mixer to adjust each track’s audio level
Built-in speaker for quick reference playback
3.5mm headphone output plus 3.5mm line output
Voice Guidance accessibility for the visually impaired
32-Bit Float audio interface for PC, Mac, iOS, and Android devices via USB-C port
Use as an interface and record to the SD card simultaneously
Using the BTA-1* Bluetooth Adapter, sync with wireless timecode devices via bluetooth
Use the BTA-1* Bluetooth Adapter to pair with the H6essential Control App for iOS
Record to SD cards up to 1TB
10 hours of battery life on AA battery (4x) or USB-C Bus Power

XY mic: XYH-6e	90º XY stereo format
	Directionality	Unidirectional
	Sensitivity	−42dB/1Pa at 1kHz
	Maximum sound pressure input	135 dB SPL
MIC/LINE (mono)	Connectors	4 XLR/TRS combo jacks
		(XLR：2 HOT TRS：TIP HOT）
	Input gain	Adjustment unnecessary (dual A/D converter circuits used)
	Input impedance	MIC (XLR) : 3.8 kΩ or more
		LINE (TRS) : 39 kΩ or more
	Maximum input level	MIC (XLR) : +4 dBu
		LINE (TRS) : +24 dBu
	Phantom power	+48 V
		Channel total 32 mA or less
	Equivalent input noise	MIC (XLR) : -120 dBu or less（IHF-A) @150 Ω input
		LINE (TRS) : -95 dBu or less（IHF-A) @600 Ω input

LINE OUT	Connector	Stereo mini jack
	Maximum output level	+1 dBu
	Output impedance	110 Ω or less
Headphones	Connector	Stereo mini jack
	Maximum output level	20 ｍW + 20 ｍW（when 32 Ω load）
	Output impedance	10 Ω or less
Built-in speaker	Type	20 mm x 30mm elliptical dynamic speaker
	Effective maximum output	250mW

Maximum simultaneous recording tracks	8
Maximum simultaneous playback tracks	6
Recording formats	WAV
	44.1/48/96 kHz,
	32-bit float mono/stereo
	BWF and iXML formats supported
	MP3
	128kbps , 256kbps, 320kbps
Recording media	4-32GB cards compatible with the microSDHC specification
	64GB–1TB cards compatible with the microSDXC specification

2.0-inch full-color LCD	360 x 240

Connector		USB Type-C
		• Use a USB cable that supports data transfer.
Audio Interface		USB 2.0 High Speed
	Input and output channels	6 in / 2 out (Multi)
		2 in / 2 out (Stereo)
	Sampling frequency	44.1/48/96 kHz (AIF only)
		44.1/48 kHz (AIF + onboard recording)
	Bit depth	24-bit, 32-bit float
File transfer		USB 2.0 High Speed

Dedicated wireless adapter	ZOOM BTA-1

4 AA batteries	Alkaline, lithium or rechargeable NiMH batteries
AC Adapter	ZOOM AD-17 (DC 5 V/1 A)
	• USB bus power is supported.
